tesa® 58346

90 µm single-sided transparent PET filmic tape

Product Features
  • Easy removal without adhesive residue.
  • Excellent electrical insulation property when it applies on surface with dielectric strength 132.1kV/mm.
  • Easy for converting and die-cutting.
Product description

The tackified acrylic adhesive gives this product outstanding removability without residue while using for temporary protection on surface. The 75 µm transparent PET filmic backing offers excellent electrical insulation property. The PET liner ensures it can be easily released without adhesive residue.

Product details and specifications

Product Features

  • Easy removal without adhesive residue.
  • Excellent electrical insulation property when it applies on surface with dielectric strength 132.1kV/mm.
  • Easy for converting and die-cutting.

Application Fields

  • Electrical insulation with removability for temporary protection.
Backing material PET film
Color transparent
Thickness of liner 36 µm
Total thickness 90 µm
Type of adhesive tackified acrylic
Type of liner PET film
Elongation at break 140 %
Temperature resistance long term 125 °C
Easy to remove yes
Dielectric breakdown voltage 12,000 V
Humidity resistance very good
Chemical resistance medium
Suitable for die cutting yes
Adhesion to Aluminium (initial) 0.16 N/cm
Adhesion to Steel (initial) 0.22 N/cm
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads

Download the files below for more technical details and information on this product.

Product information_tesa® 58346_en-SG 47.2 kB
Get in contact with us!

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product
automotive-epowertrain-58346 72dpi
tesa® 58346
stack of three rectangular adhesive sheets in beige and black, shown in a layered arrangement on a white background (This text has been generated by AI)
tesa® 7920
stack of three rectangular adhesive sheets in beige and black, shown in a layered arrangement on a white background (This text has been generated by AI)
tesa® 7950
tesa® 58377
stack of three rectangular adhesive sheets in beige and black, shown in a layered arrangement on a white background (This text has been generated by AI)
tesa® 7930
tesa adhesive tape layers separated showing beige top layer, transparent middle layer, and black bottom layer on white background (This text has been generated by AI)
tesa® 67350
stack of three rectangular adhesive sheets in beige and black, shown in a layered arrangement on a white background (This text has been generated by AI)
tesa® 7910
tesa adhesive tape layers separated showing beige top layer, transparent middle layer, and black bottom layer on white background (This text has been generated by AI)
tesa® 67320
three layered adhesive sheets with a brown base, a white middle layer, and a cream top layer slightly peeled back on a white background (This text has been generated by AI)
tesa® 66320
tesa adhesive tape layers separated showing beige top layer, transparent middle layer, and black bottom layer on white background (This text has been generated by AI)
tesa® 58356
tesa® 52050
Total thickness
90 µm
20 µm
50 µm
50
30 µm
50 µm
10 µm
20 µm
20 µm
130
50 µm
Type of adhesive
tackified acrylic
acrylic
acrylic
FR acrylic
acrylic
acrylic
acrylic
acrylic
acrylic
tackified acrylic
acrylic
Backing material
PET film
PET film
PET film
PET
PET film
Polyimide
PET film
Polyimide
Polyimide
PET
PET film
Temperature resistance long term
125 °C
60 °C
60 °C
70 °C
60 °C
85 °C
60 °C
85 °C
85 °C
125 °C
80 °C
Dielectric breakdown voltage
12,000 V
1,500 V
4,500 V
4,500 V
3,500 V
3,700 V
1,500 V
2,400 V
3,600 V
13,330 V
Temperature resistance short term
130 °C
130 °C
125 °C
130 °C
140 °C
130 °C
140 °C
140 °C
140 °C
Tensile strength
8.7 N/cm
36.7 N/cm
20 N/cm
20 N/cm
8.7 N/cm
13 N/cm
20 N/cm
165
