Double Sided Heat-Activated Film

Double Sided Heat-Activated Film

When heat and pressure are applied, the tape is activated, ultimately becoming an extremely high bond adhesive of more than 12/mm² at 25°C.



Features of tesa Heat-Activated Adhesives

tesa heat activated films (HAF) are based on a nitrile rubber and phenolic resin. They differ from normal adhesive tapes in that the adhesive characteristics are activated by both heat as well as pressure instead of just pressure: they are also not tacky at room temperature.

Our heat-activated tape offer a very high bond strength (>12N/mm² at 25°C) - nearly 5 times that of a high performance double sided tape, tesa 4965, very wide service temperature range from as low as -50°C to as high as 500°C, and excellent resistance to chemicals and solvents.

Applications of Heat-Activated Tape

tesa heat-activated adhesive films and tapes are used in many industries and are compatible with many products – and very often with those that conventional adhesive tapes are not.

Typical applications include splicing of roofing and waterproof membranes which are coated with liquid bitumen, fibreglass mats which have low dimensional stability requiring strong splices, and aluminium rolls where resistance to very high temperatures and tensile stresses as well as various solvents is essential.

They are also now widely used in the consumer electronics industry due to their ageing and shock resistance, particularly for embedding chips into smartcards.

Find out more below about our wide-ranging tape selections with heat-activated adhesion.

Read more

Show filters
tesa® HAF 8401
Specifications
none
nitrile rubber / phenolic resin
200 µm
tesa® HAF 8402
Specifications
none
nitrile rubber / phenolic resin
125 µm
tesa® HAF 8410
Specifications
none
nitrile rubber / phenolic resin
60 µm
tesa® HAF 8412
Specifications
none
nitrile rubber / phenolic resin
tesa® HAF 8451
Specifications
none
nitrile rubber / phenolic resin
200 µm
tesa® HAF 8454
Specifications
none
nitrile rubber / phenolic resin
100 µm
tesa® HAF 8471
Specifications
none
nitrile rubber / phenolic resin
30 µm
tesa® HAF 8472
Specifications
none
nitrile rubber / phenolic resin
60 µm
tesa® HAF 8473
Specifications
none
nitrile rubber / phenolic resin
80 µm
tesa® HAF 8474
Specifications
none
nitrile rubber / phenolic resin
100 µm
tesa® HAF 8476
Specifications
none
nitrile rubber / phenolic resin
150 µm
tesa® HAF 8478
Specifications
none
nitrile rubber / phenolic resin
200 µm
tesa® HAF 58470
Specifications
none
nitrile rubber / phenolic resin
50 µm
tesa® HAF 58471
Specifications
none
nitrile rubber / phenolic resin
30 µm
tesa® HAF 58474
Specifications
none
nitrile rubber / phenolic resin
100 µm
tesa® HAF 58475
Specifications
none
nitrile rubber / phenolic resin
125 µm
tesa® HAF 58476
Specifications
none
nitrile rubber / phenolic resin
150 µm
tesa® HAF 58478
Specifications
none
nitrile rubber / phenolic resin
200 µm
tesa® 58493
Specifications
PET
nitrile rubber / phenolic resin
83 µm
