Product information

tesa® 4174

Product description

tesa® 4174 is a flexible, temperature resistant PVC fineline masking tape with a rubber adhesive for a wide range of design painting requirements

  • no shrinking at high temperatures
  • conforms to the dimensional change during oven-drying
  • no edge lifting off and removable without leaving any residues
  • good conformability to multi dimensional surfaces

Main applications

Masking & Design, for wide range of fineline applications



Technical properties

Backing material

PVC film

Total thickness

110 µm

Type of adhesive

natural rubber

Adhesion to steel

3.7 N/cm

Elongation at break

200 %

Tensile strength

25 N/cm

Temperature resistance

150 °C

Temperature resistance (PP-EPDM)

150 °C

Temperature resistance (paint)

150 °C

Rating properties

Hand tearability


Easy to remove


Suitable for die cutting


Paint anchorage


Sharp colour edge


Powerwash resistance




Flame retardant


Additional Info

tesa® 4174 in small width (

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
