tesa® Process Tapes for flexo printing

TAPES FOR FLEXOGRAPHIC PRINTING PROCESS

Roller wrapping, plate edge sealing, core starting and failure flagging are just a few examples from our wide range of complementary tapes. Flexo printing tapes are available with film, cloth, and MOPP backing.

Our Complementary Products for Flexographic Printing

Illustration of a red paint roller with a white spiral pattern, shown mid-roll on a blue and white background. The roller appears to be applying a white coating using tesa tape. (This text has been generated by AI)

Plate Mounting Tape

Efficiency is key to profitability. Complementary solutions based on pressure-sensitive adhesive technology speed up changeovers, prevent machine stops and facilitate everyday tasks.
Roller wrapping tapes, plate edge sealing, UV measuring, plate cleaning and failure flagging tapes facilitate an efficient and reliable printing process and are just some examples of the well-conceived solutions tesa offers in addition to plate mounting tapes  and splicing tapes for flexographic printing.

Roller Wrap Tapes

The tesa Printer’s Friend® line is specially designed for roller wrapping applications. Roller wrapping is used in a variety of popular roller system based manufacturing and printing processes to process materials such as textiles, paper, and films. Industries where roller wrapping tapes are commonly used include:

  • Printing industry
  • Textiles industry
  • Adhesive tape manufacturers
  • General, web-based processing & converting industries



Our decades of experience in manufacturing roller wrapping tapes has made the Printer’s Friend® roller tapes an industry benchmark, loved by operators of roller utilizing machines across different industries.

The benefits of tesa Printer’s Friend® roller tapes:

  • Clean and accurate application
  • Easily removable even after a prolonged period of time
  • Ability to securely keep its position on the roller
  • Exceptionally temperature resistant
  • Outstanding grip and traction to provide tension in the web being processed
  • Repel a variety of substances involved in the process (e.g. adhesives or inks)
  • Highly resistant to wear

The tesa Printer’s Friend® range includes the following two products:

tesa Printer’s Friend® 4563

Cloth backing and a smooth silicone coated surface, offering reliable grip and repelling a variety of substances.

tesa Printer’s Friend® 4863

Uniquely treated cloth fabric coated with a combination of silicones and rubber to leave it dimpled, resembling the surface of a basketball.

Printer's Friend

Two rolls of tesa Printers Friend tape are shown. The left roll, labeled 4563, has a smooth surface. The right roll, labeled 4863, features an embossed surface. A close-up shows the texture of the embossed tesa tape. (This text has been generated by AI)
1 / 1

printers friend

Product Application Process

  1. Wrap the tape once around the roller at the desired angle and mark the point where the end of the roll meets the second turn of the tape
  2. Put the tape on a flat surface and cut it diagonally from the end of the roll to the marked point of the tape
  3. Remove the liner and start applying the tape, starting from the edge of the roller
  4. Keep on wrapping the roller with the tape at even angles, leaving no gaps in between the layers

Product Application Process

Plate edge sealing tesa® 4244 PV2, tesa® 4287
Failure flagging tesa® 4104
Core starting tesa® 64621
Roller wrapping tesa® 4863, tesa® 4563
Zero-speed splicing tesa® 4104, tesa® 4137
1 / 5

Plate edge sealing tesa® 4244 PV2, tesa® 4287

2 / 5

Failure flagging tesa® 4104

3 / 5

Core starting tesa® 64621

4 / 5

Roller wrapping tesa® 4863, tesa® 4563

5 / 5

Zero-speed splicing tesa® 4104, tesa® 4137

Roller Wrap Tape Application Design

The object is a cylindrical item with a textured surface featuring numerous small, raised circular patterns. The background is a plain, light gray color, creating a contrast that highlights the intricate details of the object. The tesa tape extends horizontally across the frame. (This text has been generated by AI)
1 / 1

Complete roller spiral wrapped, providing grip and a non-stick surface.

Other designs of wrapping are also possible. Starting from the middle and wrapping to the ends aids in pulling the material evenly across the roller to eliminate creases.

Close-up image of a textured cylindrical object. The surface features a uniform pattern with small, circular, raised elements covering the entirety of the visible area. The objects color is light gray, and it is positioned diagonally against a plain background, resembling the quality and precision you might find in tesa tape products. (This text has been generated by AI)
1 / 1

other designs of wrapping
Downloads
Brochure – Paper & Print
tesa Printer's Friend® – Setting Standards Brochure – Paper & Print PDF 415.7 kB
