tesa® 4173 PV2

เทป PVC อ่อนนุ่ม สำหรับการพัน ห่อหุ้มแบบมาตรฐาน ในส่วนของห้องโดยสารรถยนต์


Product description

tesa® 4173 PV2 เป็นเทปฟิล์มพีวีซีหุ้มสายไฟ กาวชนิดอะคริลิค

คุณสมบัติที่สำคัญ:

  • ทนต่ออุณหภูมิ 105 ° C / 3000ชั่วโมง
  • มีความยืดหยุ่น
  • ฉีกได้ด้วยมือ

สี: ดำ


รายละเอียดผลิตภัณฑ์และข้อมูลเฉพาะ

Application Fields

tesa® 4173 ออกแบบสำหรับใช้งานในส่วนห้องโดยสารสำหรับงานพันสายสายไฟ ทนถึงระดับอุณหภูมิได้ถึง 105°C
ความหนารวม 126 µm
ประเภทกาว อะครีลิค
วัสดุตัวเทป PVC film
การยืดตัวเมื่อขาด 250 %
ความทนต่อแรงดึง 30 N/cm
ความต้านทานความร้อนที่อุณหภูมิต่ำสุด -25 °C
แรงดันไฟฟ้าเบรกดาวน์ 7,000 V
ทนต่อการขัดถู (แกนหมุน 5 มม., LV312) Class A
ทนต่อการขัดถู (แกนหมุน 10 มม., LV312) Class A
ลดเสียงรบกวน (LV312) Class A
ค่าการต้านทานความร้อนสูงสุด 105 °C
การยึดเกาะกับเหล็ก 1.8 N/cm
ความกว้างมาตรฐาน: 9, 19, 25, 32 มม.
ความยาวมาตรฐาน: 33 ม.

1 สามารถคละความกว้างและความยาวได้
1 ขนาดอื่น ๆ สามารถมีได้ตามความต้องการของลูกค้า

1 เส้นผ่าศูนย์แกนมาตรฐาน: 38 มม.
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads

ดาวน์โหลดไฟล์ด้านล่างเพื่อข้อมูลทางเทคนิคและข้อมูลเพิ่มเติมเกี่ยวกับผลิตภัณฑ์นี้

Get in contact with us!

ติดต่อเรา

ขอบคุณสำหรับข้อความ

ทางเราจะติดต่อกลับโดยเร็วที่สุด

Something went wrong. Please try again later.

เปรียบเทียบผลิตภัณฑ์

ชื่อผลิตภัณฑ์ tesa® 4173 PV2 tesa® Sleeve 51036 PV7 tesa® 51623 tesa® 51608 tesa® 69000 tesa® 51616 ID tesa® 51626 tesa® Supersleeve 51036 PV6 tesa® 51025 PV10 tesa® 88103 tesa® 68000 PV1 DC
ความหนารวม
126 µm
485 µm
250 µm
280 µm
350 µm
650 µm
1,000 µm
530 µm
150 µm
250 µm
210 µm
ประเภทกาว
อะครีลิค
advanced acrylic
rubber based
rubber based
advanced acrylic
rubber based
อะครีลิค
advanced acrylic
rubber based
อะครีลิค
อะครีลิค
วัสดุตัวเทป
PVC film
PET cloth
PET / non-woven
PET fleece
PA cloth
PET fleece
PA velour
PET cloth
PET cloth
PET cloth
aluminium laminated glasscloth
ค่าการต้านทานความร้อนสูงสุด
105 °C
150 °C
105 °C
105 °C
125 °C
105 °C
105 °C
150 °C
125 °C
150 °C
150 °C
การยึดเกาะกับเหล็ก
1.8 N/cm
5.5 N/cm
2 N/cm
3 N/cm
3.5 N/cm
3 N/cm
3.1 N/cm
5 N/cm
6.5 N/cm
3.3 N/cm
6 N/cm
ความต้านทานความร้อนที่อุณหภูมิต่ำสุด
-25 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
