tesa® 62309

PE 필름 테이프


Product description

tesa® 62309 제품은 자동차 와이어하니스의 기본 번들용으로 설계된 PE 필름 테이프입니다. 일정한 풀림력, 유연한 백킹 및 손으로 찢을 수 있어 부드럽고 효율적으로 적용이 가능합니다.

tesa® 62309 수작업용 최적화 제품

특성:

  • 할로겐 프리
  • 부드럽고 유연한
  • 손으로 찢을 수 있는
  • 3000h 동안 최대 125°C의 내온도성
  • 환경영향에 대한 내성
  • 지속적인 풀림력 – 수동 작업에 최적화
  • Flag-resistant
  • 내노화성
  • 난연제
  • 냄새가 덜남


제품 세부 사항 및 사양

Application Fields

tesa® 62309 has been especially designed for efficient basic bundling application requirements at elevated temperatures. The main application field is the automotive passenger compartment.
기재 소재 PE 필름
점착제 종류 아크릴
총두께 95
연신률 100 %
인장강도 16
내마모성 (10mm mandrel, LV312) Class A
소음 댐핑 (LV312) Class A
최저 내열도 -40 °C
내마모성 (5mm mandrel, LV312) Class A
최대 내열도 125 °C
Steel점착력 2 N/cm
Standard widths: 9, 19, 25, 32 mm
Standard lengths: 33 m
  • Most combinations of width and length are possible
  • Further dimensions are available upon request

  • Standard core diameter: 38 mm
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads

이 제품에 대한 자세한 기술 세부 정보와 정보를 얻으려면 아래 파일을 다운로드하십시오.

연락주세요!

연락처

메시지 보내주셔서 감사합니다.

최대한 빨리 연락드리겠습니다.

Something went wrong. Please try again later.

제품 비교

제품명 tesa® 62309 tesa® 4182 PV2 tesa® 62250 tesa® 51623 tesa® 51608 PV0 tesa® 51616 ID tesa® Supersleeve 51036 PV6 tesa® 51025 PV10 tesa® Spiralsleeve 51026 PV5 tesa® Sleeve 51026 PV9 tesa® 51616
총두께
95
104 µm
72
250 µm
280 µm
650 µm
530 µm
150 µm
530 µm
220 µm
650 µm
점착제 종류
아크릴
아크릴
수용성 아크릴
고무 기반
고무 기반
고무 기반
개선된 아크릴
고무 기반
아크릴
아크릴
고무 기반
기재 소재
PE 필름
PVC필름
BOPP
PET / 부직포
PET 양모
PET 양모
PET천
PET천
PET천
PET천
PET 양모
최대 내열도
125 °C
105 °C
125 °C
105 °C
105 °C
105 °C
150 °C
125 °C
150 °C
150 °C
105 °C
Steel점착력
2 N/cm
1.8 N/cm
2.5 N/cm
2 N/cm
3 N/cm
3 N/cm
5 N/cm
6.5 N/cm
5.5 N/cm
5.5 N/cm
3 N/cm
최저 내열도
-40 °C
-25 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
-40 °C
