tesa® 75013 Low VOC
Product details and specifications
Product Construction
| Backing material | none |
|---|---|
| Colour | transparent |
| Colour of liner | brown/blue logo |
| Thickness of tape | 130 µm |
| Total thickness | 130 µm |
| Type of adhesive | tackified acrylic |
| Type of liner | glassine |
Product Construction
| Backing material | none |
|---|---|
| Colour | transparent |
| Colour of liner | brown/blue logo |
| Thickness of tape | 130 µm |
| Total thickness | 130 µm |
| Type of adhesive | tackified acrylic |
| Type of liner | glassine |
Properties / Performance Values
| Temperature resistance max. | 180 °C |
|---|---|
| Low VOC | very good |
| Tack | very good |
| Temperature resistance min. | -40 °C |
| Suitable for die cutting | yes |
| Fogging | good |
| Suitable for rough surfaces | very good |
Properties / Performance Values
| Temperature resistance max. | 180 °C |
|---|---|
| Low VOC | very good |
| Tack | very good |
| Temperature resistance min. | -40 °C |
| Suitable for die cutting | yes |
| Fogging | good |
| Suitable for rough surfaces | very good |
Adhesion to Values
| Adhesion to ABS (initial) | 11 N/cm |
|---|---|
| Adhesion to ABS (after 3 days) | 11 N/cm |
| Adhesion to PC (initial) | 13.9 N/cm |
| Adhesion to PC (after 3 days) | 15.1 N/cm |
| Adhesion to PE (initial) | 6.5 N/cm |
| Adhesion to PE (after 3 days) | 6.9 N/cm |
| Adhesion to PET (initial) | 7.5 N/cm |
| Adhesion to PET (after 3 days) | 8.2 N/cm |
| Adhesion to PP (initial) | 6 N/cm |
| Adhesion to PP (after 3 days) | 7 N/cm |
| Adhesion to PS (initial) | 11.3 N/cm |
| Adhesion to PS (after 3 days) | 11.7 N/cm |
| Adhesion to PVC (initial) | 6.4 N/cm |
| Adhesion to PVC (after 3 days) | 13.3 N/cm |
| Adhesion to Steel (initial) | 10.7 N/cm |
| Adhesion to Steel (after 3 days) | 10.4 N/cm |
Adhesion to Values
| Adhesion to ABS (initial) | 11 N/cm |
|---|---|
| Adhesion to ABS (after 3 days) | 11 N/cm |
| Adhesion to PC (initial) | 13.9 N/cm |
| Adhesion to PC (after 3 days) | 15.1 N/cm |
| Adhesion to PE (initial) | 6.5 N/cm |
| Adhesion to PE (after 3 days) | 6.9 N/cm |
| Adhesion to PET (initial) | 7.5 N/cm |
| Adhesion to PET (after 3 days) | 8.2 N/cm |
| Adhesion to PP (initial) | 6 N/cm |
| Adhesion to PP (after 3 days) | 7 N/cm |
| Adhesion to PS (initial) | 11.3 N/cm |
| Adhesion to PS (after 3 days) | 11.7 N/cm |
| Adhesion to PVC (initial) | 6.4 N/cm |
| Adhesion to PVC (after 3 days) | 13.3 N/cm |
| Adhesion to Steel (initial) | 10.7 N/cm |
| Adhesion to Steel (after 3 days) | 10.4 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads
Download the files below for more technical details and information on this product.
