tesa® 62934

Double-sided PE-foam mounting tape

Product description

tesa® 62934 is a double-sided PE-foam tape for constructive mounting applications. It consists of a highly conformable PE-foam backing and a tackified acrylic adhesive.

Product benefits:

Versatile adhesive for high immediate adhesion on numerous substrates
High ultimate adhesion level for a secure bonding performance
UV, water and ageing resistant
Compensates for differing thermal expansion of dissimilar materials
High immediate bonding strength even at low bonding pressure
Very good cold shock absorbtion

Product details and specifications

Application Fields

Decorative aluminium cover screens on brown goods
Doorhandles in kitchen furniture
Moulded plastic parts
Mirrors and coloured glass panels

Backing material	PE foam
Colour	black/white
Total thickness	800 µm
Type of adhesive	tackified acrylic

Elongation at break	250 %
Tensile strength	8 N/cm
Humidity resistance	very good
Static shear resistance at 40°C	good
Ageing resistance (UV)	good
Temperature resistance long term duration	80 °C
Temperature resistance short term duration	80 °C
Tack	good
Static shear resistance at 23°C	good
Softener resistance	medium

Adhesion to ABS (initial)	17 N/cm
Adhesion to ABS (after 14 days)	17 N/cm
Adhesion to Aluminium (initial)	17 N/cm
Adhesion to Aluminium (after 14 days)	17 N/cm
Adhesion to PC (initial)	15 N/cm
Adhesion to PC (after 14 days)	17 N/cm
Adhesion to PE (initial)	2.7 N/cm
Adhesion to PE (after 14 days)	2.8 N/cm
Adhesion to PET (initial)	12.5 N/cm
Adhesion to PET (after 14 days)	17 N/cm
Adhesion to PP (initial)	2.8 N/cm
Adhesion to PP (after 14 days)	5.5 N/cm
Adhesion to PS (initial)	15 N/cm
Adhesion to PS (after 14 days)	17 N/cm
Adhesion to PVC (initial)	17 N/cm
Adhesion to PVC (after 14 days)	17 N/cm
Adhesion to Steel (initial)	17 N/cm
Adhesion to Steel (after 14 days)	17 N/cm

Liner variants:
PV0 brown glassine paper (71 µm)
PV14 white PE-coated paper (120 µm)
PV10 red filmic liner (120 µm)

tesa® 62934 has been tested by TÜV Rheinland, Germany. The test confirms the longterm adhesion performance after IEC 61215 / 61646 climate tests and a 85°C temperature resistance. (TÜV report number 21209595).

Peel Adhesion:
- immediate: foam splitting on Steel, Aluminium, ABS
- after 14 days: foam splitting on Steel, Aluminium, ABS, PC, PS, PET, PVC

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.

Downloads

Download the files below for more technical details and information on this product.

Bonding Performance tesa 62934 Solar Modules TÜV 103.7 kB tesa 6293x Family Skin contact - statement 124.6 kB Product information_tesa® 62934_en-MA_fr-MA 61.5 kB

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Name of product	tesa® 62934	tesa® flameXtinct 45001	tesa® 62510	tesa® 62932	tesa® 4976	tesa® 4957	tesa® 62936	tesa® 62935	tesa® 64958	tesa® 62934	tesa® 73900
Total thickness	800 µm	1,000 µm	1,000 µm	500 µm	540 µm	1,100 µm	1,600	1,000 µm	1,050		500 µm
Type of adhesive	tackified acrylic	FR acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	synthetic rubber		modified acrylic
Backing material	PE foam	FR PE foam	PE foam	PE foam	PU foam	PE foam	PE foam	PE foam	PE foam		PE foam with film lamination
Colour	black/white	white	black/white	black/white	black	black/white	black/white	black/white	white		red
Adhesion to Steel (initial)	17 N/cm	19.2 N/cm	13.5 N/cm	13 N/cm	10 N/cm	4 N/cm	16 N/cm	17 N/cm	4 N/cm		3.5 N/cm
Adhesion to Steel (after 14 days)	17 N/cm	22 N/cm	13.5 N/cm	17 N/cm	12 N/cm	4 N/cm	19 N/cm	17 N/cm	4 N/cm
Adhesion to PVC (initial)	17 N/cm		13.5 N/cm	14.5 N/cm	5.5 N/cm	4 N/cm	19 N/cm	8 N/cm	4 N/cm
