tesa® 62932

Double-sided PE foam tape for constructive mounting


Product description

tesa® 62932 foam tape offers an excellent long term adhesive performance for demanding constructive applications where there is a small design gap.

tesa® 62932 offers the following benefits:

  • Thin foam backing allows to implement a small design gap
  • High immediate bonding strength for fast and reliable assembly even at low pressure
  • Conformable foam backing compensates for design tolerances or uneven surfaces
  • High ultimate adhesive strength for secure bonding performance
  • Very good humidity resistance
  • Shock absorption during transport and in daily use


Product details and specifications

Application Fields

  • Decorative aluminium cover screens on brown goods
  • Doorhandles in kitchen furniture
  • Moulded decorative profiles for refrigerators or freezers
  • Glass and mirror panels

Product Construction

Backing material PE foam
Colour black/white
Total thickness 500 µm
Type of adhesive tackified acrylic

Properties / Performance Values

Elongation at break 270 %
Tensile strength 8 N/cm
Static shear resistance at 23°C good
Ageing resistance (UV) good
Temperature resistance long term duration 80 °C
Humidity resistance very good
Temperature resistance short term duration 80 °C
Tack good
Static shear resistance at 40°C good
Chemical resistance good
Softener resistance medium

Adhesion to Values

Adhesion to ABS (initial) 14 N/cm
Adhesion to ABS (after 14 days) 17 N/cm
Adhesion to Aluminium (initial) 13 N/cm
Adhesion to Aluminium (after 14 days) 17 N/cm
Adhesion to PC (initial) 9 N/cm
Adhesion to PC (after 14 days) 17 N/cm
Adhesion to PE (initial) 1.7 N/cm
Adhesion to PE (after 14 days) 3 N/cm
Adhesion to PET (initial) 12.5 N/cm
Adhesion to PET (after 14 days) 17 N/cm
Adhesion to PP (initial) 1.8 N/cm
Adhesion to PP (after 14 days) 3.3 N/cm
Adhesion to PS (initial) 10.5 N/cm
Adhesion to PS (after 14 days) 17 N/cm
Adhesion to PVC (initial) 14.5 N/cm
Adhesion to PVC (after 14 days) 17 N/cm
Adhesion to Steel (initial) 13 N/cm
Adhesion to Steel (after 14 days) 17 N/cm

Additional Info

Liner variants:
PV0 brown glassine paper (71 µm)
PV14 white PE-coated paper (122 µm)
PV10 red filmic liner (120 µm)

Peel Adhesion:
- after 14 days: foam splitting on Steel, Aluminium, ABS, PC, PS, PET, PVC
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
