tesa® 88002 Optical Clear Adhesive
OCA 50um Tahan Pelepasan Gas Otomotif
produk fitur
- Performa ketahanan terhadap pelepasan gas yang sangat baik
- Versi tipis dengan solusi 50 μm
- Memenuhi kondisi pengujian standar otomotif yang penting
Product description
Produk kami, tesa® 88002 memiliki ketahanan terhadap pelepasan gas yang tak tertandingi dengan versi 50 um, yang dirancang untuk unggul bahkan dalam kondisi penuaan yang paling berat sekalipun. Ideal untuk laminasi tanpa batas pada head-up display dan aplikasi permukaan pintar, produk ini menjamin integrasi yang mudah dan daya tahan yang lama
Detail Produk dan Spesifikasi
produk fitur
- Performa ketahanan terhadap pelepasan gas yang sangat baik
- Versi tipis dengan solusi 50 μm
- Memenuhi kondisi pengujian standar otomotif yang penting
- Transmisi tinggi, kabut rendah, dan perubahan YI rendah
- Performa ketahanan suhu dan UV yang luar biasa
Application Fields
tesa® 88002 OCA cocok untuk laminasi optik dengan,
- HUD
- Permukaan pintar
- Laminasi cermin
Properties / Performance Values
Kabut | 0 % |
---|---|
Indeks bias | 1.48 |
Pengisian celah | 20 % |
Transmitansi (380 - 780 nm) > | 99 % |
Dielektrik konstan | 5.6 |
Ageing resistance (UV) | very good |
Properties / Performance Values
Kabut | 0 % |
---|---|
Indeks bias | 1.48 |
Pengisian celah | 20 % |
Transmitansi (380 - 780 nm) > | 99 % |
Dielektrik konstan | 5.6 |
Ageing resistance (UV) | very good |
Adhesion to Values
Daya rekat ke Kaca (awal) | 5.9 N/cm |
---|---|
Daya rekat ke PC (awal) | 6.6 N/cm |
Adhesion to Values
Daya rekat ke Kaca (awal) | 5.9 N/cm |
---|---|
Daya rekat ke PC (awal) | 6.6 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
