Product Construction
Backing material | non-woven |
Color | โปร่งแสง |
Color of liner | สีน้ำตาล |
Thickness of liner | 80 µm |
Total thickness | 100 µm |
Type of adhesive | type: water-based acrylic |
Type of liner | type: glassine |
Weight of liner | 90 g/m² |
tesa® 52210 เป็นเทปเยื่อกระดาษอะคริลิกสูตรน้ำที่มีความหนา 100 µm เทปนี้ได้รับการพัฒนาขึ้นโดยเฉพาะสำหรับงานติด และงานแปรรูปทุกประเภท เนื่องจากคุณสมบัติ VOC ต่ำจึงได้รับการออกแบบมาโดยเฉพาะเพื่อตอบสนองความต้องการภายในรถยนต์
tesa® 52210 เหมาะสำหรับการเคลือบพื้นผิวโฟม ขนแกะ และผ้าสักหลาดทุกชนิด
ผลิตภัณฑ์นี้มีขนาด 150 µm (tesa® 52215).
คุณสมบัติหลัก:
Backing material | non-woven |
Color | โปร่งแสง |
Color of liner | สีน้ำตาล |
Thickness of liner | 80 µm |
Total thickness | 100 µm |
Type of adhesive | type: water-based acrylic |
Type of liner | type: glassine |
Weight of liner | 90 g/m² |
Backing material | non-woven |
Color | โปร่งแสง |
Color of liner | สีน้ำตาล |
Thickness of liner | 80 µm |
Total thickness | 100 µm |
Type of adhesive | type: water-based acrylic |
Type of liner | type: glassine |
Weight of liner | 90 g/m² |
Suitable for die cutting | ใช่ |
Elongation at break | 5 % |
Tensile strength | 10 N/cm |
การทนต่ออุณหภูมิระยะเวลาสั้น | 200 °C |
Static shear resistance at 23°C | กลาง |
ความต้านทานความร้อนที่อุณหภูมิต่ำสุด | -40 °C |
Humidity resistance | ดี |
การทนต่ออุณหภูมิระยะเวลายาว | 80 °C |
Tack | ดี |
Ageing resistance (UV) | ดีมาก |
Suitable for die cutting | ใช่ |
Elongation at break | 5 % |
Tensile strength | 10 N/cm |
การทนต่ออุณหภูมิระยะเวลาสั้น | 200 °C |
Static shear resistance at 23°C | กลาง |
ความต้านทานความร้อนที่อุณหภูมิต่ำสุด | -40 °C |
Humidity resistance | ดี |
การทนต่ออุณหภูมิระยะเวลายาว | 80 °C |
Tack | ดี |
Ageing resistance (UV) | ดีมาก |
Adhesion to ABS (initial) | 6.1 N/cm |
Adhesion to ABS (after 14 days) | 9.5 N/cm |
Adhesion to Aluminium (initial) | 3.9 N/cm |
Adhesion to Aluminium (after 14 days) | 7.1 N/cm |
Adhesion to PC (initial) | 7.3 N/cm |
Adhesion to PC (after 14 days) | 8.7 N/cm |
Adhesion to PE (initial) | 2 N/cm |
Adhesion to PE (after 14 days) | 3 N/cm |
Adhesion to PET (initial) | 4.3 N/cm |
Adhesion to PET (after 14 days) | 7.8 N/cm |
Adhesion to PP (initial) | 3.2 N/cm |
Adhesion to PP (after 14 days) | 3.6 N/cm |
Adhesion to PS (initial) | 7.9 N/cm |
Adhesion to PS (after 14 days) | 9.4 N/cm |
Adhesion to PVC (initial) | 7.1 N/cm |
Adhesion to PVC (after 14 days) | 8.5 N/cm |
Adhesion to Steel (initial) | 6 N/cm |
Adhesion to Steel (after 14 days) | 11.2 N/cm |
Adhesion to ABS (initial) | 6.1 N/cm |
Adhesion to ABS (after 14 days) | 9.5 N/cm |
Adhesion to Aluminium (initial) | 3.9 N/cm |
Adhesion to Aluminium (after 14 days) | 7.1 N/cm |
Adhesion to PC (initial) | 7.3 N/cm |
Adhesion to PC (after 14 days) | 8.7 N/cm |
Adhesion to PE (initial) | 2 N/cm |
Adhesion to PE (after 14 days) | 3 N/cm |
Adhesion to PET (initial) | 4.3 N/cm |
Adhesion to PET (after 14 days) | 7.8 N/cm |
Adhesion to PP (initial) | 3.2 N/cm |
Adhesion to PP (after 14 days) | 3.6 N/cm |
Adhesion to PS (initial) | 7.9 N/cm |
Adhesion to PS (after 14 days) | 9.4 N/cm |
Adhesion to PVC (initial) | 7.1 N/cm |
Adhesion to PVC (after 14 days) | 8.5 N/cm |
Adhesion to Steel (initial) | 6 N/cm |
Adhesion to Steel (after 14 days) | 11.2 N/cm |
ดาวน์โหลดไฟล์ด้านล่างเพื่อข้อมูลทางเทคนิคและข้อมูลเพิ่มเติมเกี่ยวกับผลิตภัณฑ์นี้
