tesa® 6925 Temperature-Resistant Label Stock

Printable, self-adhesive and tamper-evident

Product Features
  • tesa® 6925 even resists brazing and cleaning processes.
  • The acrylic film is self-adhesive and printable with high contrast which leads to a high initial readability rate; even on high density barcodes.
  • The dimensionally stable material is resistant against chemicals, abrasion, temperature, ageing and UV-light.
All product features

Product description

tesa® 6925 marking foil is especially recommended when high durability and superb resistance against the highest temperature are required.

This high performance product is used as a tamper-evident identification sealing label over the entire lifetime of a product and also as a data carrier system for intelligent in-process steering. A typical application is the marking of circuit boards.
Available in: white

Product Features

  • tesa® 6925 even resists brazing and cleaning processes.
  • The acrylic film is self-adhesive and printable with high contrast which leads to a high initial readability rate; even on high density barcodes.
  • The dimensionally stable material is resistant against chemicals, abrasion, temperature, ageing and UV-light.
  • The adhesive system consists of a resin modified acrylic suitable even for low energy surfaces.

Application Fields

  • Highly durable and resistant against chemicals, abrasion temperature and UV-light
  • Very good adhesion on various substrates
  • Tamper Evident: Not removable without destruction

Product Construction

Type of liner coated paper
Weight of liner 65 g/m²
Backing material Acrylic
Type of adhesive acrylic
Thickness of tape 90 µm

Properties / Performance Values

Adhesive weight 25 g/m²
Ageing resistance (UV) very good
Chemical resistance very good
Frost resistance -50 °C
Humidity resistance very good
Peel off force from liner 2-6
Shelf life time 24 months
Suitable laser Yb:YAG
Tamper evidence Yes
Temperature resistance long term 120 °C
Temperature resistance short term 270 °C

Additional Info

Printability:
Sheet screen printing is recommended. Paint adherence and chemical resistance need to be evaluated on a case to case basis.

Thermal Transfer:
tesa® 6925 is suitable for precise and high contrast thermal transfer printing.
The quality of the marking depends on the combination of printer and ribbon. In order to achieve the best results, the printing speed and the temperature of the curing bar should be varied.

Dimensions:
Width: on request, length: 300m
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
