tesa® 51495 PV2
Reinforced Aluminum Foil Tape
Product Features- Release liner for ease of unwind
- Vapor barrier
- Heat and radiation reflective properties
Product description
tesa® 51495 PV2 consists of aluminium foil reinforced with polyethylene scrim which is coated with a synthetic rubber based adhesive.
Product Features
- Release liner for ease of unwind
- Vapor barrier
- Heat and radiation reflective properties
- Excellent adhesion to own backing
Application Fields
- Joining roofing and wall insulation
- Wrapping of pipes
- Sealing air conditioning ducts
Product Construction
| Type of liner | paper |
| Backing material | aluminium foil |
| Type of adhesive | synthetic rubber |
| Total thickness | 205 µm |
| Color | silver |
| Color of liner | white |
| Thickness of liner | 85 µm |
| Thickness of tape |
Properties / Performance Values
| Elongation at break | 20 % |
| Tensile strength | 45 N/cm |
| Hand tearability | no |
| Liner release force | 0.3 N/cm |
| Operation temperature from | -20 °C |
| Operation temperature up to | 80 °C |
| Temperature resistance min. | -20 °C |
Adhesion to Values
| Adhesion to Steel | 9 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
