tesa® 50204 Low VOC
180 µm tackified acrylic adhesive with hand-tearable PE backing for cable mounting applications in automotive interiors
Product description
tesa® 50204 is a hand-tearable PE filmic tape with a high performance acrylic adhesive and a thickness of 180 µm for applications in automotive interiors. Due to its low VOC property it is particularly designed to meet automotive interior requirements.tesa® 50204 is especially designed for cable mounting on different kinds of automotive interior components.
Main features
- Excellent shear and peel resistance
- Low VOC (according to GB 27630) – no critical substances detectable
- Suitable for common irregular, rough, and critical surfaces
- Low and stable unwind force
- Suitable for automatic tape dispensers
- Linerless
Main applications
tesa® 50204 is suitable for quick and secure fixation of flat and round cables to headliners via straight tape stripes.Additional Info
tesa’s automation and application department provides customized equipment and self-designed application tools to enhance productivity.Adhesion values to:
PET
PET fleece surface
PET fleece Headliner A
are not part of the product specification
Technical properties
Thickness of tape
180 µm
Elongation at break
28 %
Type of adhesive
tackified acrylic
Tensile strength
17.5 N/cm
Backing material
PE
Color
blue-translucent
Adhesion properties
Adhesion to PET fleece surface (initial)
12.1 N/cm
Adhesion to PET fleece Headliner A (after 3 days)
7.4 N/cm
Adhesion to PET fleece surface (after 3 days)
13 N/cm
Adhesion to PET fleece Headliner A (initial)
7.8 N/cm
Adhesion to PET (initial)
8.7 N/cm
Adhesion to PET (after 3 days)
9 N/cm
Rating properties
Conformability
++
Static shear resistance
++
Tack
++
Static peel resistance
++
Temperature resistance short term
200 °C
Hand tearability
++
Low VOC
+
Suitable for rough surfaces
++
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
