tesa_633xx_dr_001
Product information

tesa® 63308

80µm double sided transparent tape



Product description

tesa® 63308 is a double-sided mounting tape with a special reworkable adhesive

tesa® 63308 features:
  • Thickness: 80µm
  • High bonding strength
  • Very high push out and shock resistance
  • High performance on LSE substrates
  • Excellent permanent reworkability on various substrates
  • After separation the adhesive is reworkable by stretching or peeling
  • Easy reworkability even after a long bonding time


Main applications

  • Demanding mounting
  • Permanent mounting of components in electronic devices with the option to remove the parts for repairing or recycling
  • Temporary mounting prior to mechanical fixation

Technical properties

Type of adhesive

specialty

Type of liner

glassine

Total thickness

80 µm

Backing material

none

Color

transparent

Adhesion properties

Adhesion to Steel (initial)

9 N/cm

Adhesion to PE (initial)

6 N/cm

Adhesion to PC (after 14 days)

10 N/cm

Adhesion to PC (initial)

8 N/cm

Adhesion to Glass (after 14 days)

9 N/cm

Adhesion to PE (after 14 days)

8 N/cm

Adhesion to Glass (initial)

8 N/cm

Adhesion to Steel (after 14 days)

10 N/cm

Rating properties

Removability after 14 days (23°C)

++

Static shear resistance at 23°C

++

Temperature resistance long term

60 °C

Static shear resistance at 40°C

++

Temperature resistance short term

90 °C

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
