Product Construction
Backing material | ultra thin non-woven |
Color | โปร่งแสง |
Color of liner | logo สีขาว/แดง |
Thickness of liner | 71 µm |
Total thickness | 30 µm |
Type of adhesive | type: tackified acrylic |
Weight of liner | 82 g/m² |
เทป non-woven โปร่งแสง กาวสองหน้า 30 ไมครอน
tesa® 8851 เป็นเทป non-woven กาวสองด้าน แบบบางพิเศษ ทนต่ออุณหภูมิดีเยี่ยม เหมาะสำหรับการติดประกอบ micro-speaker dome และการติด FPC .
tesa® 8851 ทำจากกาว tackified acrylic และ backing เป็น non-woven แบบบางพิเศษ ทนต่ออุณหภูมิได้ถึง 260 องศาเซลเซียส และมีประสิทธิภาพที่ยอดเยี่ยมในการ converting แผ่นไลเนอร์กลาสซีนทนต่ออุณหภูมิซึ่งมั่นใจได้ว่าจะดึงออกได้ง่ายหลังจากขั้นตอนการบัดกรี
คุณสมบัติพิเศษของ tesa® 8851 :
Backing material | ultra thin non-woven |
Color | โปร่งแสง |
Color of liner | logo สีขาว/แดง |
Thickness of liner | 71 µm |
Total thickness | 30 µm |
Type of adhesive | type: tackified acrylic |
Weight of liner | 82 g/m² |
Backing material | ultra thin non-woven |
Color | โปร่งแสง |
Color of liner | logo สีขาว/แดง |
Thickness of liner | 71 µm |
Total thickness | 30 µm |
Type of adhesive | type: tackified acrylic |
Weight of liner | 82 g/m² |
Adhesion to ABS (initial) | 3.4 N/cm |
Adhesion to ABS (after 14 days) | 4.6 N/cm |
Adhesion to Aluminium (initial) | 3.5 N/cm |
Adhesion to Aluminium (after 14 days) | 5.5 N/cm |
Adhesion to PC (initial) | 3.7 N/cm |
Adhesion to PC (after 14 days) | 5 N/cm |
Adhesion to PET (initial) | 4 N/cm |
Adhesion to PET (after 14 days) | 4.4 N/cm |
Adhesion to PI (initial) | 4.3 N/cm |
Adhesion to PI (after 14 days) | 4.4 N/cm |
Adhesion to Steel (initial) | 4 N/cm |
Adhesion to Steel (after 14 days) | 5.5 N/cm |
Adhesion to ABS (initial) | 3.4 N/cm |
Adhesion to ABS (after 14 days) | 4.6 N/cm |
Adhesion to Aluminium (initial) | 3.5 N/cm |
Adhesion to Aluminium (after 14 days) | 5.5 N/cm |
Adhesion to PC (initial) | 3.7 N/cm |
Adhesion to PC (after 14 days) | 5 N/cm |
Adhesion to PET (initial) | 4 N/cm |
Adhesion to PET (after 14 days) | 4.4 N/cm |
Adhesion to PI (initial) | 4.3 N/cm |
Adhesion to PI (after 14 days) | 4.4 N/cm |
Adhesion to Steel (initial) | 4 N/cm |
Adhesion to Steel (after 14 days) | 5.5 N/cm |
ดาวน์โหลดไฟล์ด้านล่างเพื่อข้อมูลทางเทคนิคและข้อมูลเพิ่มเติมเกี่ยวกับผลิตภัณฑ์นี้
