Product Construction
Backing material | PET film |
Color | สีดำ |
Color of liner | สีขาวพร้อมด้วย tesa logo |
Thickness of liner | 71 µm |
Total thickness | 50 µm |
Type of adhesive | type: tackified acrylic |
Type of liner | type: glassine |
เทปฟิล์มสีดำ กาวสองหน้า 50ไมครอน
tesa® 7650 เป็นเทปกาวสองหน้า ประกอบด้วย backing ชนิด PET สีดำ และกาวtackified acrylicสีดำ
คุณสมบัติพิเศษ:
Backing material | PET film |
Color | สีดำ |
Color of liner | สีขาวพร้อมด้วย tesa logo |
Thickness of liner | 71 µm |
Total thickness | 50 µm |
Type of adhesive | type: tackified acrylic |
Type of liner | type: glassine |
Backing material | PET film |
Color | สีดำ |
Color of liner | สีขาวพร้อมด้วย tesa logo |
Thickness of liner | 71 µm |
Total thickness | 50 µm |
Type of adhesive | type: tackified acrylic |
Type of liner | type: glassine |
Elongation at break | 50 % |
Tensile strength | 20 N/cm |
Transmittance (380 - 780nm) < | 0.6 % |
Tack | กลาง |
การทนต่ออุณหภูมิระยะเวลาสั้น | 150 °C |
Ageing resistance (UV) | ดีมาก |
Static shear resistance at 40°C | ดี |
Dielectric breakdown voltage | 4000 V |
Humidity resistance | ดี |
Softener resistance | ดีมาก |
Elongation at break | 50 % |
Tensile strength | 20 N/cm |
Transmittance (380 - 780nm) < | 0.6 % |
Tack | กลาง |
การทนต่ออุณหภูมิระยะเวลาสั้น | 150 °C |
Ageing resistance (UV) | ดีมาก |
Static shear resistance at 40°C | ดี |
Dielectric breakdown voltage | 4000 V |
Humidity resistance | ดี |
Softener resistance | ดีมาก |
Adhesion to ABS (initial) | 5 N/cm |
Adhesion to ABS (after 14 days) | 5 N/cm |
Adhesion to Glass (initial) | 5 N/cm |
Adhesion to Glass (after 14 days) | 6 N/cm |
Adhesion to PE (initial) | 2.8 N/cm |
Adhesion to PE (after 14 days) | 4 N/cm |
Adhesion to PET (initial) | 4 N/cm |
Adhesion to PET (after 14 days) | 5 N/cm |
Adhesion to Steel (initial) | 5 N/cm |
Adhesion to Steel (after 14 days) | 7 N/cm |
Adhesion to ABS (initial) | 5 N/cm |
Adhesion to ABS (after 14 days) | 5 N/cm |
Adhesion to Glass (initial) | 5 N/cm |
Adhesion to Glass (after 14 days) | 6 N/cm |
Adhesion to PE (initial) | 2.8 N/cm |
Adhesion to PE (after 14 days) | 4 N/cm |
Adhesion to PET (initial) | 4 N/cm |
Adhesion to PET (after 14 days) | 5 N/cm |
Adhesion to Steel (initial) | 5 N/cm |
Adhesion to Steel (after 14 days) | 7 N/cm |
ดาวน์โหลดไฟล์ด้านล่างเพื่อข้อมูลทางเทคนิคและข้อมูลเพิ่มเติมเกี่ยวกับผลิตภัณฑ์นี้
