Product Construction
Backing material | conductive foam |
Color | สีเทา |
Color of liner | logo สีขาว/น้ำเงิน |
Thickness of liner | 120 µm |
Total thickness | 300 µm |
Type of adhesive | type: conductive acrylic |
Type of liner | type: PE-coated paper |
เทปโฟมสีเทาสองหน้านำไฟฟ้า 300µm
tesa® 60246 เป็นเทปกาวด้านเดียว สีเทา เทปโฟมนำไฟฟ้า ประกอบด้วยเนื้อโฟมที่มีรอยปรุเคลือบด้วยสารนำไฟฟ้าและกาวนำไฟฟ้า
tesa® 60246 คุณสมบัติพิเศษ .
Backing material | conductive foam |
Color | สีเทา |
Color of liner | logo สีขาว/น้ำเงิน |
Thickness of liner | 120 µm |
Total thickness | 300 µm |
Type of adhesive | type: conductive acrylic |
Type of liner | type: PE-coated paper |
Backing material | conductive foam |
Color | สีเทา |
Color of liner | logo สีขาว/น้ำเงิน |
Thickness of liner | 120 µm |
Total thickness | 300 µm |
Type of adhesive | type: conductive acrylic |
Type of liner | type: PE-coated paper |
การทนต่ออุณหภูมิระยะเวลาสั้น | 160 °C |
แรงต้านพื้นผิวบนแนวแกน xyz | 0.2 mOhm |
Release of liner | ลอกง่าย |
Contact resistance z-direction (initial) | 0.03 Ohm / square inch |
การทนต่ออุณหภูมิระยะเวลาสั้น | 160 °C |
แรงต้านพื้นผิวบนแนวแกน xyz | 0.2 mOhm |
Release of liner | ลอกง่าย |
Contact resistance z-direction (initial) | 0.03 Ohm / square inch |
Adhesion to Steel (after 14 days) | 5.3 N/cm |
Adhesion to Steel (after 14 days) | 5.3 N/cm |
ดาวน์โหลดไฟล์ด้านล่างเพื่อข้อมูลทางเทคนิคและข้อมูลเพิ่มเติมเกี่ยวกับผลิตภัณฑ์นี้
